Malaysia Hot Sale
Max flow:5.2m³/h
Max head:50m
Medium temperature range:0~55℃
Max operating pressure: 6bar
Voltage range: 160-250V
Speed: 1500-3000rpm
Insulation class: Class F
Description
Hydrobox is a highly intelligent variable frequency boosting system that integrates constant pressure, quiet operation, precise real-time pressure, power, and speed parameter displays. It also boasts a professional mode for effortless manual pressure adjustments.
Features
AIO Water Pressure System
Perfect Water Pressure Integrated Inverter Control System Constant Pressure at any time
Breakthrough of Pump Energy-saving Variable -frequency permanent magnet motor Low consumption and compact structure
Permanent Magnet motor comes with 85% motor efficiency and Multiple Protections
LED display, with longer service life than the LCD screen
Small volume, gaining more possibilities to install
Up to 55℃ Liquid temp, for more guarantee
Comes with a Quick Installation Kit, making it easy for home application.
8 protective measures
Application
It is designed to handle the pressure boosting in residential buildings and villas.
Pressure boosting of city mains water
Pressure boosting of roof tank, break tank and ground tank
Water supply from shallow wells
Working Conditions
Maximum ambient temperature up to +40℃
Maximum fluid temperature up to 55℃
Maximum pressure up to 6 bar
Upgradeable Waterproof Module for Wet Environments
